MINI LED CONTACT SWITCH
$25.00
Bocatech’s Mini LED 5A Push Button Contact On/Off Switch. Stylish and unobtrusive.
FEATURES:
- Stainless Steel 316 (Marine Rated)
- Large 0.6” diameter, various color LED rings clearly indicate status of power
- Available in on/off & momentary
- Used for 12 & 24VDC marine and automotive systems
- Electrical life: 50,000 cycles
|
SPECIFICATIONS |
|
|
1IP67/IK08 Rated |
waterproof |
|
Dimension |
0.6" diameter |
|
Mechanical Life |
1,000,000 cycles |
|
Operation Travel |
about 3.1mm |
|
Operation Pressure |
3-5N |
|
LED Life |
40,000 hours |
|
Operating Temperature |
-20°C - +55°C |
|
Outer Diameter |
19mm |
|
Panel Thickness |
1-10mm |
|
Contact Resistance |
50mΩ |
|
Insulation Resistance |
1000M |
|
MODEL |
TYPE |
LED COLOR |
|
BTSSS-24BL |
On/Off |
Blue |
|
BTSSS-24MBL |
Momentary |
Blue |
|
BTSSS-24RD |
On/Off |
Red |
|
BTSSS-24MRD |
Momentary |
Red |
|
BTSSS-12BL |
On/Off |
Blue |
|
BTSSS-12MBL |
Momentary |
Blue |
|
BTSSS-12RD |
On/Off |
Red |
|
BTSSS-12MRD |
Momentary |
Red |
|
BTSSS-12MBL/R |
Momentary |
Blue/Red |
|
BTSSS-5BL |
On/Off |
Blue |
|
BTSSS-5RD |
On/Off |
Red |
|
BTSSS-5MBL/R |
Momentary |
Blue/Red |
|
BTSSS-3.3MBL |
Momentary |
Blue |
|
BTSSS-3.3MRD |
Momentary |
Red |
Harness
BTSSS-12HRN/TIN Plug & Harness Assembly for BTSSS series
Tin plated wire, 4 ft. long
Note: Wires on back of harness not shown in pictures
