DL-BLK-WHT

Flush Mounted LED Step Light - Black Housing

LED Color
Cool White (6000k)
Blue
RGB
Coating

Super compact and indirect, yet bright and efficient lighting for passageways, steps, or compartments make these LED lights ideal. The curved reflector design directs light downward, therefore eliminating any glare effect and maximizing your illumination while only protruding 3/8”.



FEATURES

  • 32 Lumens Max
  • Voltage: 12VDC
  • IP68 Rated
  • Light Style:  Step Light
  • Housing Material:  Aluminum
  • Draw: 140mA @ 12VDC
  • Viewable Angle: 150°
  • Fixture Dimensions: 7/8” dia.
  • Mounting Style: Press fit
  • Required Cutout: 5/8” dia. (with 1-1/4” bulkhead clearance)
  • Finished Clearance: 3/8”
  • Wiring: 2 conductor (single color) / 4 conductor (RGB), 22-gauge marine grade (9ft. cable supplied)
  • Warranty: Limited Lifetime





DIMENSIONS/ BEAM PATTERN

    SPECIFICATIONS

    PRODUCT SPECIFICATION SHEETS
