CORPUS - Cool White Carbon Fiber LED Deck Light - White Housing
Description
Tired of flaking aluminum? We understand that cast aluminum has no place in a corrosive environment, that's why we built the new Corpus LED deck lights out of forged carbon fiber. Say goodbye to corrosion, paint flakes, and dissimilar metals as these have no place in a marine environment. The Corpus forged carbon fiber LED deck light is made for the harshest environment and backed with our lifetime warranty.
FEATURES:
- Forged Carbon Fiber Housing
-
1,240 Lumens
- 3W CREE® LED’s - 9W Total
- 9~24V Input
- IP68 Rated
- Patent Pending Thermal Design
- Available in Black or White Housing
- 50,000 Hours Average Lifespan
- Operating Temp: -40°F ~ +165° F
- PlashLights Lifetime Warranty
- Each Light Includes: 316 Stainless Steel Hardware, 3ft Power Wire
** ALL CORPUS LED DECK LIGHTS ARE FULLY POTTED MAKING THEM COMPLETELY WATERPROOF **
CORPUS Carbon Fiber LED Deck Lights
Built for the harshest marine environments, CORPUS combines powerful LED output with a forged carbon fiber housing designed to withstand the conditions that can quickly wear down conventional metal lighting.
With 1,240 lumens from three 3W CREE® LEDs, fully potted construction and an IP68 rating, CORPUS provides bright, reliable illumination for decks, cockpits, gunwales and other areas of your boat. Choose from Cool White, Red, Amber, Blue, Green or RGB, with Black or White housing options to match your installation.
Everything You Need To Know
Key Features
Forged Carbon Fiber Housing
CORPUS uses a forged carbon fiber housing instead of conventional cast aluminum. The result is a durable housing designed for demanding marine environments without the corrosion and paint-flaking concerns associated with traditional metal housings.
1,240 Lumens of LED Output
Three 3W CREE® LEDs deliver a total of 9W of LED power and produce up to 1,240 lumens of powerful illumination.
Fully Potted & IP68 Rated
Every CORPUS LED deck light is fully potted to protect the internal components from water intrusion. The IP68 rating makes CORPUS well suited for demanding marine environments.
Patent-Pending Thermal Design
The patent-pending thermal design helps manage heat generated during operation for reliable performance.
Multiple Light Colors
Choose the lighting configuration that best fits your application. CORPUS is available in Cool White, Red, Amber, Blue, Green and RGB.
Black or White Housing
Select a Black or White forged carbon fiber housing to complement your boat and installation.
Marine-Ready Hardware
Each CORPUS light includes chrome-coated 316 stainless steel mounting hardware and a 3-foot power wire.
Built for Harsh Conditions
CORPUS is designed to operate in temperatures ranging from -40°F to +165°F and has an average lifespan of 50,000 hours.
Lifetime Warranty
Every CORPUS LED deck light is backed by the PlashLights Lifetime Warranty.
Specifications
- Product Type: Marine LED Deck Light
- LED Chips: 3 x 3W CREE® LEDs
- Total Power: 9W
- Raw Lumens: 1,240 LM
- Waterproof Rating: IP68
- Input Voltage: 9-24V DC
- Amp Draw: 2.7A @ 12V DC
- Housing: Forged Carbon Fiber
- Housing Colors: Black or White
- Light Colors: Cool White, Red, Amber, Blue, Green, or RGB
- Construction: Fully Potted
- Thermal Design: Patent-Pending
- Operating Temperature: -40°F to +165°F
- Expected Lifespan: 50,000 Hours
- Power Wire: 3 ft
- Hardware: Chrome-Coated 316 Stainless Steel
- Warranty: PlashLights Lifetime Warranty
- Country of Manufacture: USA
Installation
CORPUS is designed for a compact, clean installation on a variety of marine surfaces.
The standard mounting configuration uses the included 316 stainless steel hardware. Each light measures approximately 2.72" long × 1.58" wide × .49" deep, with mounting holes spaced approximately 2.02" apart.
For installations where the light needs to be directed at an angle, the optional RL-Angle-Mount provides an alternative mounting configuration.
For the best long-term marine installation, use an appropriate marine-grade sealant around mounting penetrations to help prevent water intrusion into the mounting surface.
Ideal Applications
CORPUS Carbon Fiber LED Deck Lights are designed for a wide range of marine lighting applications, including:
- Boat deck lighting
- Cockpit lighting
- Under-gunwale lighting
- T-top lighting
- Console lighting
- Fishing boat lighting
- Pontoon boat lighting
- Center console lighting
- Courtesy lighting
- Marine accent lighting
- Night fishing
- Exterior boat lighting
The compact housing makes CORPUS a practical choice when you need powerful illumination without taking up significant mounting space.
Color Options
Choose Your Light Color
CORPUS is available in six light color options, allowing you to choose the lighting that best fits your boat, application and nighttime environment.
Cool White
Cool White provides bright, crisp illumination for applications where visibility is the priority. It's a strong choice for boat decks, cockpits, fishing areas, storage areas and other locations where you need to clearly see what you're doing.
Red
Red lighting is a popular choice for nighttime applications where reducing perceived glare is important. It can be especially useful around fishing and navigation areas where maintaining night vision is a consideration.
Blue
Blue provides a distinctive accent-lighting appearance and is a popular choice for creating a custom look on boats and other marine applications.
Green
Green provides another distinctive lighting option and is particularly popular for fishing-focused applications and custom marine lighting.
Amber
Amber provides a warmer, lower-glare lighting option that works well for nighttime marine applications. It can be particularly useful around fishing areas, decks and cockpits where you want useful illumination without the harsher appearance of bright white or blue light.
RGB
RGB gives you the flexibility to create multiple colors from a single light, making it ideal for custom accent lighting and changing the look of your boat depending on the occasion.
Choose Your Housing Color
CORPUS is available with a Black or White forged carbon fiber housing, allowing you to match the light to your boat and installation.
Black Housing
The Black housing provides a low-profile appearance that works well with darker surfaces and many modern boat interiors and exteriors.
White Housing
The White housing provides a clean, contrasting appearance and can blend naturally with lighter-colored fiberglass, gelcoat and other surfaces.
Forged Carbon Fiber Housing
CORPUS uses a forged carbon fiber housing instead of conventional cast aluminum. The result is a durable housing designed for demanding marine environments without the corrosion and paint-flaking concerns associated with traditional metal housings.
1,240 Lumens of LED Output
Three 3W CREE® LEDs deliver a total of 9W of LED power and produce up to 1,240 lumens of powerful illumination.
Fully Potted & IP68 Rated
Every CORPUS LED deck light is fully potted to protect the internal components from water intrusion. The IP68 rating makes CORPUS well suited for demanding marine environments.
Patent-Pending Thermal Design
The patent-pending thermal design helps manage heat generated during operation for reliable performance.
Multiple Light Colors
Choose the lighting configuration that best fits your application. CORPUS is available in Cool White, Red, Amber, Blue, Green and RGB.
Black or White Housing
Select a Black or White forged carbon fiber housing to complement your boat and installation.
Marine-Ready Hardware
Each CORPUS light includes chrome-coated 316 stainless steel mounting hardware and a 3-foot power wire.
Built for Harsh Conditions
CORPUS is designed to operate in temperatures ranging from -40°F to +165°F and has an average lifespan of 50,000 hours.
Lifetime Warranty
Every CORPUS LED deck light is backed by the PlashLights Lifetime Warranty.
- Product Type: Marine LED Deck Light
- LED Chips: 3 x 3W CREE® LEDs
- Total Power: 9W
- Raw Lumens: 1,240 LM
- Waterproof Rating: IP68
- Input Voltage: 9-24V DC
- Amp Draw: 2.7A @ 12V DC
- Housing: Forged Carbon Fiber
- Housing Colors: Black or White
- Light Colors: Cool White, Red, Amber, Blue, Green, or RGB
- Construction: Fully Potted
- Thermal Design: Patent-Pending
- Operating Temperature: -40°F to +165°F
- Expected Lifespan: 50,000 Hours
- Power Wire: 3 ft
- Hardware: Chrome-Coated 316 Stainless Steel
- Warranty: PlashLights Lifetime Warranty
- Country of Manufacture: USA
CORPUS is designed for a compact, clean installation on a variety of marine surfaces.
The standard mounting configuration uses the included 316 stainless steel hardware. Each light measures approximately 2.72" long × 1.58" wide × .49" deep, with mounting holes spaced approximately 2.02" apart.
For installations where the light needs to be directed at an angle, the optional RL-Angle-Mount provides an alternative mounting configuration.
For the best long-term marine installation, use an appropriate marine-grade sealant around mounting penetrations to help prevent water intrusion into the mounting surface.
CORPUS Carbon Fiber LED Deck Lights are designed for a wide range of marine lighting applications, including:
- Boat deck lighting
- Cockpit lighting
- Under-gunwale lighting
- T-top lighting
- Console lighting
- Fishing boat lighting
- Pontoon boat lighting
- Center console lighting
- Courtesy lighting
- Marine accent lighting
- Night fishing
- Exterior boat lighting
The compact housing makes CORPUS a practical choice when you need powerful illumination without taking up significant mounting space.
Choose Your Light Color
CORPUS is available in six light color options, allowing you to choose the lighting that best fits your boat, application and nighttime environment.
Cool White
Cool White provides bright, crisp illumination for applications where visibility is the priority. It's a strong choice for boat decks, cockpits, fishing areas, storage areas and other locations where you need to clearly see what you're doing.
Red
Red lighting is a popular choice for nighttime applications where reducing perceived glare is important. It can be especially useful around fishing and navigation areas where maintaining night vision is a consideration.
Blue
Blue provides a distinctive accent-lighting appearance and is a popular choice for creating a custom look on boats and other marine applications.
Green
Green provides another distinctive lighting option and is particularly popular for fishing-focused applications and custom marine lighting.
Amber
Amber provides a warmer, lower-glare lighting option that works well for nighttime marine applications. It can be particularly useful around fishing areas, decks and cockpits where you want useful illumination without the harsher appearance of bright white or blue light.
RGB
RGB gives you the flexibility to create multiple colors from a single light, making it ideal for custom accent lighting and changing the look of your boat depending on the occasion.
Choose Your Housing Color
CORPUS is available with a Black or White forged carbon fiber housing, allowing you to match the light to your boat and installation.
Black Housing
The Black housing provides a low-profile appearance that works well with darker surfaces and many modern boat interiors and exteriors.
White Housing
The White housing provides a clean, contrasting appearance and can blend naturally with lighter-colored fiberglass, gelcoat and other surfaces.
Traditional metal light housings can be vulnerable to the effects of a harsh marine environment. Saltwater, moisture and exposure to the elements can eventually contribute to corrosion, paint deterioration and flaking.
CORPUS takes a different approach with a forged carbon fiber housing designed specifically for demanding applications.
The result is a lightweight, durable housing that eliminates many of the corrosion and finish concerns associated with traditional cast aluminum housings.
For boat owners who demand more from their marine lighting, CORPUS combines high-output LED performance with a housing built for the environment it's going into.
Yes. The optional RL-Angle-Mount is available for installations where an angled mounting position is preferred.
CORPUS can be used for a variety of marine lighting applications, including boat decks, cockpits, gunwales, T-tops, consoles, fishing areas and other exterior lighting applications.
CORPUS Carbon Fiber LED Deck Light FAQs
Whether you're lighting a boat deck, cockpit, gunwale or another exterior area, CORPUS provides powerful illumination in a compact, marine-ready package.
What is a CORPUS Carbon Fiber LED Deck Light?
CORPUS is a high-output marine LED deck light featuring a forged carbon fiber housing, three 3W CREE® LEDs and fully potted construction. Each light produces up to 1,240 lumens and is IP68 rated for demanding marine applications.
What makes the CORPUS housing different from a traditional aluminum deck light?
CORPUS uses a forged carbon fiber housing instead of conventional cast aluminum. This eliminates concerns associated with corrosion and paint flaking that can occur with traditional metal housings in harsh marine environments.
Is the CORPUS LED deck light waterproof?
Yes. CORPUS is IP68 rated and fully potted to protect the internal components from water intrusion.
How bright is the CORPUS LED deck light?
Each CORPUS light produces up to 1,240 lumens using three 3W CREE® LEDs, for a total LED power of 9W.
What voltage does CORPUS use?
CORPUS is designed for 9–24VDC input with an amp draw of 2.7A at 12VDC.
Can CORPUS be used for underwater lighting?
CORPUS is IP68 rated and fully potted, but it should not automatically be marketed as an underwater light unless PlashLights specifically approves the product for continuous underwater use. For dedicated underwater applications, use a purpose-built PlashLights underwater light.
How long do CORPUS LED deck lights last?
CORPUS has an average lifespan of approximately 50,000 hours.
